Amer Stainless, based in Amman, Jordan, stands out as a leading manufacturer and supplier of top-notch Stainless Steel 316/316L Sanitary Tubing. They provide dependable solutions for industries that need hygienic and corrosion-resistant piping systems. With a reputation for precision engineering, cutting-edge manufacturing techniques, and rigorous quality control, Amer Stainless guarantees that each tubing product adheres to international standards for performance and durability. Their 316/316L Sanitary Tubing is specifically designed for critical sanitary applications where cleanliness, strength, and long-lasting reliability are crucial. This tubing is widely utilized in the pharmaceutical, food and beverage, and biotechnology sectors, solidifying the company’s status as a trusted source for stainless steel solutions.
Stainless Steel 316/316L Sanitary Tubing is an austenitic alloy that contains around 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, providing outstanding resistance to corrosion in acidic and chloride-rich environments. The 316L version has a low carbon content, which helps prevent carbide precipitation and enhances weldability. In terms of mechanical properties, 316/316L tubing boasts high tensile and yield strength, excellent ductility, and dependable toughness. Its smooth surface finish, stability at elevated temperatures, and resistance to pitting, crevice, and intergranular corrosion make it perfect for sanitary applications that require durability, hygiene, and structural integrity.
| ASTM | ASTM A270 / ASME SA 270 |
| Material | SS 304, SS 304L,SS 316,SS 316L |
| Outer Diameter | 1/2 Inch |
| Wall Thickness | 16 Gauge (0.065 Inch) |
| Length | 20 Feet |
| Finish | 20Ra Inner Diameter/ 32Ra Outer Diameter |
| Outer Diameter Tolerance | +/-0.005” / +/-0.13MM |
| Wall Thickness Tolerance | +/-10% |
| Length Tolerance | +1/8” / +3.18MM |
| Mill Test Certificate | EN10204 3.1 |
| Standard | 3A / ASTM A270 / A270M |
| Type | Seamless / Welded |
| Polish | Mechanical Polished / Electropolished |
| Certification | ASME BPE/ 3-A SSI |
| Grade | Carbon | Manganese | Phosphorus | Sulfur | Silicon | Chromium | Nickel | Molybdenum |
| TP304 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | |
| TP304L | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | |
| TP316 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 |
| TP316L | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| Material | Temperure | Yield Strength | Heat | Tensile Strength | Elongation |
| Min. º F(º C) | Ksi (MPa), Min. | Treatment | Ksi (MPa), Min. | ||
| TP304 | 1900 (1040) | 30(205) | Solution | 75(515) | 35 |
| TP304L | 1900 (1040) | 25(170) | Solution | 70(485) | 35 |
| TP316 | 1900(1040) | 30(205) | Solution | 75(515) | 35 |
| TP316L | 1900(1040) | 25(170) | Solution | 70(485) | 35 |
Contact us to get a quick quote for your requirement.
We ensure absolute clarity and premium quality assurance with our Stainless Steel 316/316L Sanitary Tubing. Each order is supplied with a comprehensive set of documentation, including a commercial invoice, packing list, fumigation certificate, heat treatment records, and NABL-certified laboratory test reports. In addition, we provide Material Test Certificates (EN 10204/3.1b), Positive Material Identification (PMI) test reports, detailed radiographic examination records, and Third-Party Inspection Certificates. Our structured documentation process is meticulously designed to guarantee maximum transparency, reinforce client trust, and deliver complete satisfaction.
It is high-purity tubing made from 316/316L stainless steel, designed for hygienic applications like food, beverage, dairy, and pharmaceuticals.
316L has a lower carbon content than 316, offering better resistance to corrosion and making it ideal for welding applications.
Excellent corrosion resistance, durability, smooth internal finish, and compliance with sanitary standards.
Yes, it is usually manufactured to ASTM A270, ASME BPE, and other global sanitary tubing standards.
Stainless Steel 316/316L Sanitary Tubing finds extensive use in industries that require hygienic, corrosion-resistant piping systems. It’s commonly used in pharmaceutical and biotechnology facilities for transferring liquids under sanitary conditions, ensuring processes remain contamination-free. The food and beverage industry also relies on these tubes for processing milk, juice, and other liquids, thanks to their smooth surface and ease of cleaning.
