Amer Stainless, based in Amman, Jordan, has earned a solid reputation as a reliable manufacturer and supplier of top-quality Stainless Steel Sanitary Tubing. This tubing is specifically designed to meet the strict hygiene and safety standards required in sensitive industries. With a focus on precision craftsmanship and compliance with global standards, Amer Stainless delivers tubing that boasts an exceptional surface finish, impressive corrosion resistance, and long-lasting durability. The company employs cutting-edge manufacturing technologies and rigorous quality inspections to guarantee a contamination-free product that ensures smooth flow performance. Catering to the pharmaceutical, food, beverage, dairy, and biotechnology sectors, Amer Stainless is committed to providing dependable sanitary tubing solutions characterized by consistent quality, timely delivery, and a customer-centric approach.
When it comes to Stainless Steel Sanitary Tubing, the materials typically used include grades 304, 304L, 316, and 316L. These grades are composed of chromium (18–20%) and nickel (8–12%), with 316/316L also containing molybdenum (2–3%) to enhance corrosion resistance. The low carbon content in these grades improves weldability and helps prevent carbide precipitation. In terms of mechanical properties, the tubing offers a tensile strength ranging from 520 to 750 MPa and a yield strength between 170 and 450 MPa, along with excellent elongation, hardness, and thermal stability. The smooth internal finish of the tubing ensures superior cleanliness, minimal product retention, and optimal flow performance in sanitary processing environments.
| ASTM | ASTM A270 / ASME SA 270 |
| Material | SS 304, SS 304L,SS 316,SS 316L |
| Outer Diameter | 1/2 Inch |
| Wall Thickness | 16 Gauge (0.065 Inch) |
| Length | 20 Feet |
| Finish | 20Ra Inner Diameter/ 32Ra Outer Diameter |
| Outer Diameter Tolerance | +/-0.005” / +/-0.13MM |
| Wall Thickness Tolerance | +/-10% |
| Length Tolerance | +1/8” / +3.18MM |
| Mill Test Certificate | EN10204 3.1 |
| Standard | 3A / ASTM A270 / A270M |
| Type | Seamless / Welded |
| Polish | Mechanical Polished / Electropolished |
| Certification | ASME BPE/ 3-A SSI |
| Grade | Carbon | Manganese | Phosphorus | Sulfur | Silicon | Chromium | Nickel | Molybdenum |
| TP304 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | |
| TP304L | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | |
| TP316 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 |
| TP316L | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| Material | Temperure | Yield Strength | Heat | Tensile Strength | Elongation |
| Min. º F(º C) | Ksi (MPa), Min. | Treatment | Ksi (MPa), Min. | ||
| TP304 | 1900 (1040) | 30(205) | Solution | 75(515) | 35 |
| TP304L | 1900 (1040) | 25(170) | Solution | 70(485) | 35 |
| TP316 | 1900(1040) | 30(205) | Solution | 75(515) | 35 |
| TP316L | 1900(1040) | 25(170) | Solution | 70(485) | 35 |
Contact us to get a quick quote for your requirement.
We ensure absolute clarity and premium quality assurance with our Stainless Steel Sanitary Tubing. Every order is supported by comprehensive documentation, including a commercial invoice, packing list, fumigation certificate, heat treatment records, and NABL-certified lab test reports. In addition, we provide Material Test Certificates as per EN 10204/3.1b, PMI Test Reports, complete radiographic examination details, and Third-Party Inspection Certificates. Our structured documentation system is designed to deliver maximum transparency, client confidence, and satisfaction.
Stainless steel sanitary tubing is specially manufactured tubing designed for hygienic applications where cleanliness and corrosion resistance are critical, such as in food, beverage, pharmaceutical, and biotech industries.
The most common grades are 304/304L and 316/316L stainless steel. Grade 316L is preferred for its superior corrosion resistance, especially in applications involving harsh chemicals or saline environments.
It is widely used in dairy, brewery, winery, food processing, pharmaceutical manufacturing, biotechnology, and cosmetics industries, where sterile and contamination-free fluid transfer is essential.
Sanitary tubing usually complies with standards like ASTM A270, ASME BPE, and 3-A Sanitary Standards, ensuring smooth finishes, precise dimensions, and strict hygienic quality control.
Stainless Steel Sanitary Tubing is a go-to choice in industries where purity, hygiene, and contamination-free performance are non-negotiable. In the food and beverage world, it plays a crucial role in milk lines, beverage transfer systems, brewery pipelines, and processing equipment. When it comes to pharmaceuticals and biotechnology, this tubing is vital for handling sterile fluids, purification systems, and cleanroom piping. The dairy, cosmetics, and chemical sectors also depend on sanitary tubing to safely and efficiently transfer sensitive products. Thanks to its smooth surface, resistance to corrosion, and easy cleaning, Stainless Steel Sanitary Tubing guarantees reliable and hygienic operation in all applications where sanitation is key.
